Reading MCAP Files#

MCAP is an open-source container file format for multimodal log data, commonly used in robotics and autonomous systems. Daft can read MCAP files using [daft.read_mcap()][daft.io.read_mcap].

Basic Usage#

1
2
3
4
import daft

df = daft.read_mcap("/path/to/recording.mcap")
df.show()

1
2
3
4
5
6
import daft
from daft.io import IOConfig, S3Config

io_config = IOConfig(s3=S3Config(region_name="us-west-2"))
df = daft.read_mcap("s3://bucket/recordings/data.mcap", io_config=io_config)
df.show()

1
2
3
4
import daft

df = daft.read_mcap("https://example.com/recordings/session.mcap")
df.show()

1
2
3
4
5
import daft

# Read all MCAP files in a directory
df = daft.read_mcap("/recordings/")
df.show()

Output Schema#

The read_mcap function returns a DataFrame with the following schema:

Column Type Description
source_path string Path of the MCAP file containing the message
topic string The topic name the message was published on
log_time uint64 Timestamp when the message was logged (nanoseconds)
publish_time uint64 Timestamp when the message was published (nanoseconds)
sequence uint32 Sequence number of the message
data binary Raw message payload

If use_legacy_types=True, the DataFrame schema will match the legacy implementation.

Column Type Description
source_path string Path of the MCAP file containing the message
topic string The topic name the message was published on
log_time int64 Timestamp when the message was logged (nanoseconds)
publish_time int64 Timestamp when the message was published (nanoseconds)
sequence int32 Sequence number of the message
data string Message payload

Deprecated use_legacy_types=True flag

use_legacy_types=True is deprecated and will be removed in v0.9.0. Update your script to use the currently emitted column types.

Filtering Options#

Time Range#

Filter messages by time range. The time unit matches the MCAP log_time field (typically nanoseconds):

1
2
3
4
5
6
df = daft.read_mcap(
    "/path/to/recording.mcap",
    start_time=1609459200000000000,  # 2021-01-01 UTC in nanoseconds
    end_time=1609545600000000000,    # 2021-01-02 UTC in nanoseconds
)
df.show()

Unsigned timestamp bounds

Ensure that start_time, end_time, and times returned by topic_start_time_resolver must be between 0 and 2**64 - 1 to match the internal MCAP timestamp format. Negative time values raise OverflowError.

Topic Filtering#

Read only specific topics:

1
2
3
4
5
df = daft.read_mcap(
    "/path/to/recording.mcap",
    topics=["/camera/image", "/lidar/points"],
)
df.show()

Batch Size#

Control memory usage by adjusting the batch size:

1
2
3
4
df = daft.read_mcap(
    "/path/to/recording.mcap",
    batch_size=500,  # Number of messages per batch (default: 1000)
)

Advanced: Topic Start Time Resolver#

For advanced use cases, you can provide a callable that computes per-file, per-topic start times. This is useful for resuming reads from specific positions:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
def get_topic_start_times(file_path: str) -> dict[str, int]:
    """Return a mapping of topic names to start times."""
    # Your logic to determine start times per topic
    return {
        "/camera/image": 1609459200000000000,
        "/lidar/points": 1609459200500000000,
    }

df = daft.read_mcap(
    "/path/to/recording.mcap",
    topic_start_time_resolver=get_topic_start_times,
)

When a resolver is provided: - One scan task is created per (file, topic) combination - The task's start_time is set to max(start_time, resolver(file)[topic])

Use Cases#

Robotics Data Processing#

1
2
3
4
5
6
7
8
9
import daft
from daft import col

# Read sensor data
df = daft.read_mcap("/recordings/*.mcap", topics=["/imu/data"])

# Filter and process
recent_data = df.where(col("log_time") > 1609459200000000000)
recent_data.show()

Multi-Topic Analysis#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
import daft
from daft import col

# Read multiple topics
df = daft.read_mcap(
    "/recordings/session.mcap",
    topics=["/camera/image", "/gps/fix", "/vehicle/speed"],
)

# Group by topic
topic_counts = df.groupby("topic").count()
topic_counts.show()
